BEFANBY manufacture the lifting transfer cart, simply speaking, it is a transfer cart with lifting deck, it is good choice when some workpiece need lift some height to work.

Warranty: 2 Years
Capacity: 1-1,500 tons
Certificate: CE SGS ISO9001, SASO
OEM: Support
Vulnerable Parts: Give as gifts
Advantage: Peculiar set-up makes the transfer cart save cost and operate more conveniently
Product Description

BEFANBY manufacture the lifting transfer cart, simply speaking, it is a transfer cart with lifting deck, it is good choice when some workpiece need lift some height to work.which dramatically reduce the material handling requirements of cranes and forklifts while providing quick, safe and smooth movement of materials and products through manufacturing facilities. Our lifting transfer cart is available in a number of configurations specifically designed to suit the needs of our customers.

The types of lifts BEFANBY cars can achieve:

1.Column Lift (2/4 hydraulic cylinder)

2.Scissor Lift (2/4 hydraulic cylinder)

3.Tilting

All BEFANBY can recommend economic and excellent solution you on your working site.

Main Feature:

1.Customized load capacity from 1 ton to 1,500 tons
2.Optional Table Size, Platform Structure
3.Optional power source(Conductor rail/ battery/ cable/ diesel powered)
4.Optional working method(rails or no rails)
5.Box girder structure cart frame(nondeformable, Unique Structure)
6.Customized system(lifting, weighing, titling, climbing, ferry, plc, etc.)
7.Optional Control System (Radio Control / Remote Controller / Cabin)
8.Safety System(LED flashing lights, Sound acoustic devices, E-stop, Dead man stop, Buffer, etc.)
9.Speed up to 10 Km/h
10.Well known components brand.



Product parameters
Technical Parameter Of Lifting Transfer Cart
Model KPJ Remark
QTY 1 SET
Solution Profile Workshop Transport mold
Load Capacity (T) 10 Custom Capacity over 1,500T
Table Size (mm) 3600(L)*7000(W)*800(H) Box Girder Structure
Lifting Height(mm) 12000
Rail Inner Gauge (mm) 5949
Power Supply Cable drum Power
Motor Power(KW) 2*1KW
Motor AC Motor Support Frequency Charger
Running Speed(m/min) 0-20 Adjusted Speed
Running Distance(m) 70
Wheel Dia.(mm) 300 ZG55 Material
Power AC380V,50HZ
Recommend Rail  P24
Color Yellow Customized Color
Operation Type Hand Pendant + Remote Control
Special Design 1. lifting system
2. Double Scissor Lift
3. Horizonal Direction Moving
