Hand Operated Electric Tow Tractor
Hand Operated Electric Tow Tractor
Hand Operated Electric Tow Tractor
Hand Operated Electric Tow Tractor
Hand Operated Electric Tow Tractor
Hand Operated Electric Tow Tractor
Hand Operated Electric Tow Tractor
Hand Operated Electric Tow Tractor
Hand Operated Electric Tow Tractor
Hand Operated Electric Tow Tractor

Hand Operated Electric Tow Tractor

The electric tow tractor is powered by the battery, provides power to the motor, and drives the tractor to run.

Warranty: 2 Years
Capacity: 1-1,500 tons
Certificate: CE SGS ISO9001, SASO
Delivery Time: 20-30 working days
Product Description

The electric tow tractor is powered by the battery, provides power to the motor, and drives the tractor to run. The operation method of the tractor is handle operation. The rear end of the tractor is suspended with a tow bar, which is used to tow a 15 ton aircraft, which greatly improves the take-off and maintenance of the aircraft, which will largely promote the efficiency.

Main Features And Functions

The electric tractor is composed of cart body, battery, electric control, driving wheel, steering wheel, motor reducer, warning lamp, lighting lamp and operating handle etc.. The device is powered by its own battery, and manually operates the handle to operate the tractor, which can realize straight and turning. The device is simple to operate and flexible to turn, which can ensure the rapid towing of the aircraft.

Hand Operated Electric Tow Tractor

Product parameters
Technical Parameter Of Hand Operated Electric Tow Tractor
Model QY Remark
QTY 1 SET
Solution Profile Towing the fighter
TowingCapacity  700kg Custom Capacity over 1,500T
Table Size (mm) 2100*1100*400 Box Girder Structure
Turning Radius(mm) <=3000mm
Power Supply Maintenance Free Battery
Charger 48v/60A Customized as per the Industrial Voltage
Motor DC Motor Support Frequency Charger
Running Speed(km/h) 0-3.5 Adjusted Speed
Height of Towing Bar 180/280
Wheel Material.(mm) Polyurethane + ZG55
Color Green Customized Color
Operation Type Towing Hand Pendant
Special Design 1. U-shaped ring is reserved on the side, and the forklift position is reserved at the bottom of the tractor to facilitate forklift loading and unloading
2. Climbing Capacity: <=3 degree
